BlueDiamond MINIBLUE X87-504 Condensate Pump with Temperature Sensor

The BlueDiamond MINIBLUE X87-504 is a state-of-the-art condensate pump designed for efficient and reliable condensate removal in air conditioning systems with a capacity of up to 10 kW. Ideal for both residential and commercial HVAC installations across the UK, this pump combines cutting-edge technology, whisper-quiet operation, and flexible installation options, making it a preferred choice for professionals and homeowners.

Patented Rotary Diaphragm Technology

The MINIBLUE X87-504 is powered by BlueDiamond’s exclusive Rotary Diaphragm technology, offering peristaltic pump performance at a cost-effective price. This self-priming system delivers a consistent flow rate of 8 litres per hour, with a maximum head of 8 metres and a suction lift of 5 metres. It excels in high-lift and long-run applications, handling small debris and running dry without overheating or clogging, ensuring dependable performance.

Energy-Saving Temperature Sensor

Equipped with a hot and cold temperature sensor, the MINIBLUE X87-504 operates intelligently by activating only when a temperature differential (typically 5–6°C) is detected between the air inlet and outlet, indicating cooling mode. This feature minimises energy consumption and reduces wear, making it ideal for systems that alternate between heating and cooling, ensuring the pump runs only when condensate is produced.

Ultra-Quiet Performance

With a noise level of just 21 dB(A), the MINIBLUE X87-504 is one of the quietest condensate pumps available, making it perfect for noise-sensitive environments such as bedrooms, offices, or hotels. Its vibration-free design ensures discreet operation, allowing for comfortable use without disturbance.

Compact and Flexible Installation

Measuring 105 x 66 x 56 mm and weighing only 0.5 kg, the MINIBLUE X87-504 is designed for versatility. It can be mounted in any orientation—horizontal, vertical, or inverted—fitting seamlessly into tight spaces like cable ducts or ceiling voids. The pump includes a universal stepped adapter for easy connection to standard drip trays and a 2-metre, three-core mains cable for straightforward installation, whether for new systems or retrofits.

Maintenance-Free and Durable

The MINIBLUE X87-504 requires no routine maintenance, thanks to its robust design and ability to run wet or dry without damage. This feature prevents mould buildup in tubing, ensuring hygienic operation. Backed by a 3-year manufacturer’s warranty, the pump offers long-term reliability and peace of mind for demanding HVAC applications.

Technical Specifications

• Model: X87-504
• Flow Rate: 8 litres/hour
• Maximum Head: 8 metres
• Suction Lift: 5 metres
• Noise Level: 21 dB(A)
• Power Supply: 230V, 50 Hz, 1-phase
• Power Consumption: 0.2A (average)
• Dimensions: 105 x 66 x 56 mm
• Weight: 0.5 kg
• System Capacity: 3.5–10 kW
• Connection: 6 x 9 mm inlet/outlet (7.8 mm external diameter)
• Warranty: 3 years

Why Choose the MINIBLUE X87-504?

• Advanced Technology: Patented Rotary Diaphragm for reliable, debris-tolerant performance
• Energy Efficient: Temperature sensor optimises operation for cooling modes
• Ultra-Quiet: 21 dB(A) for discreet use in any setting
• Versatile Design: Compact and mountable in any orientation
• Low Maintenance: Runs dry without damage, preventing mould
• Trusted Quality: 3-year warranty for confidence in durability

Elevate your HVAC system with the BlueDiamond MINIBLUE X87-504, available now at AirconSpares.com. Engineered for efficiency, reliability, and ease of installation, this condensate pump is the perfect solution for managing condensate in air conditioning systems across the UK.
