Mastercool 52255 A/C System Analyzer - Professional HVAC Diagnostic Tool for Superheat, Subcool, and Airflow Testing

Mastercool 52255 A/C System Analyzer

The Mastercool 52255 A/C System Analyzer is a comprehensive diagnostic tool designed for professional HVAC technicians. This all-in-one kit, featuring the 52251 Analyzer, Round Vane, and Clamp-on Thermocouple, empowers users to perform precise diagnostics on air conditioning systems with ease and accuracy. Engineered to calculate critical metrics such as Superheat, Subcool, Airflow, and Temperature Split, this analyzer eliminates the need for manual charts, streamlining the diagnostic process.

Key Features

• Complete Diagnostic Solution: Measures Dry Bulb (DB), Wet Bulb (WB), Relative Humidity (RH), Dew Point (DP), Air Velocity, and Air Volume, alongside Superheat and Subcool calculations.
• User-Friendly Interface: Equipped with a backlit LCD display and intuitive navigation buttons (Power, Enter, Units, Calibration, and Function keys) for seamless operation.
• Quick Start Mode: Allows immediate testing without entering customer or technician details, with results saved until the test is repeated.
• Versatile Testing Options: Supports manual pressure input or automatic calculations using the included pressure transducer for Actual Superheat and Subcool testing.
• Flexible Duct Measurements: Toggle between rectangular and round duct settings for accurate Air Volume testing, with easy input for Height, Width, or Diameter.
• Data Management: Save test results under Customer, Technician, and Date using the New Entry feature, with USB connectivity for downloading data to maintain detailed records.
• Calibration Capabilities: Calibrate the thermocouple and pressure transducer for consistent accuracy, using known temperature sources or high-pressure gas with a calibrated gauge.
• Metric and Imperial Units: Toggle between PSI/Bar and °F/°C to suit your preferences, ideal for UK technicians.

Technical Specifications

• Operating Temperature: 0 to 50°C (32 to 122°F), Humidity <80%
• Dimensions: 191mm x 93mm x 41mm (with boot)
• Weight: 500g (including batteries and round vane)
• Power: 6 AA batteries
• Round Vane: Temperature Range: -20 to 60°C (-4 to 140°F), Accuracy: ±0.6°C (1.1°F), Humidity Range: 0.1% to 99.9% RH, Windspeed: 0.5 to 25 m/s
• Pressure Transducer: 0-750 psi (0-52 bar), Accuracy: ±0.5, ±1% F.S.
• Clamp-on Thermocouple: Temperature Range: -40 to 121°C (-40 to 250°F)

Applications

Ideal for HVAC professionals, the Mastercool 52255 excels in diagnosing residential and commercial air conditioning systems. Whether you're assessing Target Superheat, Actual Superheat, Subcool, or Temperature Split, this analyzer provides reliable data to ensure optimal system performance. Its ability to measure air velocity and volume makes it perfect for evaluating duct performance, while the USB port allows for easy data transfer to maintain service records.

Why Choose the Mastercool 52255?

With its robust construction, precise measurements, and user-friendly design, the Mastercool 52255 A/C System Analyzer is an essential tool for UK-based HVAC technicians. Its ability to toggle between metric and imperial units ensures compatibility with local standards, while the included accessories (Round Vane and Clamp-on Thermocouple) make it a versatile choice for comprehensive system diagnostics. Backed by Mastercool’s reputation for quality, this analyzer is a must-have for ensuring accurate refrigerant charging and system efficiency.

Order your Mastercool 52255 A/C System Analyzer from AirconSpares.com today and elevate your HVAC diagnostics to the next level!
