Little Giant VCL-24S Condensate Removal Pump

The Little Giant VCL-24S is a high-performance condensate removal pump engineered for the automatic collection and disposal of condensate from air conditioning systems, refrigeration units, dehumidifiers, and high-efficiency oil or gas-fired condensing furnaces and boilers. Ideal for both commercial and domestic settings in the UK, this pump is perfect when gravity drainage is not feasible, ensuring a clean and efficient solution for managing condensation.

Key Features

• Robust Construction: Built with a durable 1-gallon ABS plastic tank and a galvanised steel tank cover, the VCL-24S is designed for long-lasting performance.
• Powerful Motor: Equipped with a 1/18 hp, fan-cooled, concentric motor with a stainless steel shaft, delivering reliable operation and thermal protection.
• High Flow Rate: Capable of pumping up to 270 gallons per hour (GPH) at 1' lift, with a maximum lift of 24 feet, ensuring efficient condensate removal.
• Automatic Operation: Features a float-activated switch (solid polymer) for automatic start/stop functionality, with an overflow detection switch for high-level water detection (dual NO/NC operation, factory-set to NO).
• Versatile Discharge: Includes a 3/8" barbed discharge adapter for use with 3/8" I.D. vinyl tubing, with an optional check valve adapter included. An optional check valve for 3/8" O.D. copper tubing is available separately (Part Number 599063).
• Flexible Installation: Two 1-1/8" diameter inlet openings allow for easy connection to multiple systems.
• High Temperature Tolerance: Handles water temperatures up to 120°F, making it suitable for a wide range of applications.
• Convenient Power Supply: Comes with a 6 ft, 3-conductor cable with a grounded 3-prong plug for easy setup.

Applications

The VCL-24S is designed to tackle condensate removal in various scenarios, including:

• Air conditioning and refrigeration systems
• Dehumidification equipment
• High-efficiency condensing furnaces and boilers

Its vertical centrifugal pump design ensures efficient and reliable performance, making it a trusted choice for HVAC professionals and homeowners alike.

Technical Specifications

Construction Materials

• Pump Housing: ABS
• Tank: ABS
• Tank Cover: Galvanised Steel
• Motor Shaft: Stainless Steel
• Discharge Adapter: Acetal

Why Choose the VCL-24S?

The Little Giant VCL-24S offers a combination of durability, efficiency, and ease of use, making it an essential component for any HVAC system requiring condensate management. Its compact design, coupled with high-quality materials and automatic operation, ensures minimal maintenance and maximum reliability. Backed by Little Giant’s reputation for excellence, this pump is a cost-effective solution for keeping your systems running smoothly.

Available Replacement Parts

• Tank (Part No. 153502)
• Cover, Volute (Part No. 153500)
• Impeller (Part No. 153515)
• Adapter, 5/8" (Part No. 153300)
• Sealing (Part No. 924039, 950325)
• Overflow Detection Switch (Part No. 950355)

Order your Little Giant VCL-24S Condensate Removal Pump today from AirconSpares.com and ensure efficient condensate management for your HVAC systems!
